dustproof metal tube laser cutting machine , safe laser cutting machine for tubes

Product Details

Certification: ISO9001:2008

Payment & Shipping Terms:

Minimum Order Quantity: 1

Price: NEGOTIATION

Packaging Details: Wooden case

Delivery Time: 15 days

Supply Ability: 2000units

Detailed Product Description

Product Name:	Fiber Laser Cutting Machine For Metal Pipes	Laser Type:	Fiber Laser
Laser Power:	500w/800w/1000w	Laser Application:	Metal Tube Cutting
Cooling:	Water Cooling	Power Supply:	380v
Compatible Software:	Coreldraw,Autocad

Main Features

The whole fiber laser cutting machine for metal consist of machine This system consist of machine tool, motion parts, electrical equipment control parts, and other assist parts. Via control system to operation three axis motion parts, so it can drive to fiber laser cutting head achieve a stable, accurate, and high speed moving; X and Y axis adopt by imported with original packaging high quality and precision HIWIN linear guide rail, working table adopt by square pipe to welding the overall machine, stress relief annealing treat, the max load-bearing of mesa could get 500 KG, it also has universal ball bearing, machine external set up peripheral clamping device, use full enclosed dust proof device, photoelectric sensor, and other precise positioning parts to ensure accuracy of the transmission.

Advantage of Fiber laser Tube cutting machine

Clean cut edges without burr or dust formation.
Cutting of extremely fine contours and practically radius-free inner edges.
Low thermal influence,i.e., no delamination
Cutting of various material thicknesses and combinations in one operation.
Seperation of fitted printed boards.
No material deformation due to contactless material processing.
No tensioning device or protective cover necessary.
High level of precision and positional accuracy of the cut edges due to automatic recording.
Maximum utilization of circuit boards because no space has to be kept free for cutting channels.

High Precision

Satisfy Customer's claims to work the round pipe, square pipe and specially shaped metal.
It is the best choice for the professional production of pipe.

^{Technical Parameters}

^Name	^{Fiber laser cutting machine for metal pipes}
^Model	^RL-T500
^{Cutting range}	^{6m long,20-200mm diameter}
^{Laser power}	^{500w,800w,1000w,1500w,2500w,3000w}
^{Laser type}	^{Fiber laser}
^{Cooling ways}	^{Water cooling}
^{Mininum line width}	^0.1mm
^{Cutting speed}	^0-35m/min
^{Max moving speed}	^90m/min
^{Locating accuracy}	^≤0.03mm
^{repeatable accuracy}	^≤0.02mm
^{Max acceleration}	^1.5G
^{Max loading on table}	^500KG
^{Controlling software}	^CYPTUBE
^{Format supported}	^IGS
^{Software environment}	^{Windows xp/7/8/10}
^{Compatible software}	^{Coreldraw,Autocad}
^{Driving system}	^{High precisionDual driving servo motor with gear and rack}
^{Auxiliary accessories}	^{Exhaust fan,fume tubes,water chiller,tools box}
^{Working table}	^{Automatic Motorized chuck}
^{Applicable materials}	^{Carbon steel,stainess steel,brass,copper,aluminum,etc}
^{Continuous working time}	^{24 hrs each day}
^{Working environment Temperature}	^{0-45℃,Humidity5-95%(no condensate water.)}
^{Power supply}	^{220v/380v/440v,50hz/60hz}
^Weight	^4480kg
^Dimension	^{11900(L)1580(W)2260(H)mm}

Application Area

Sports equipment industry, aviation, navigation, kitchen appliances, machinery and equipment, electrical equipment, lighting hardware, auto parts, display equipment and other pipe processing industry
