precious laser cutting and engraving machine , advertising fiber cutting machine

Product Details

Certification: ISO9001:2008

Payment & Shipping Terms:

Minimum Order Quantity: 1 unit

Price: negotiation

Packaging Details: Wooden Case

Delivery Time: 7-15 days

Supply Ability: 2000 units per month

Detailed Product Description

Product Name:	Precious Fiber Laser Cutter For Advertising Industry Application 5050	Laser Power:	300w To 800w
Working Area:	500*500mm	Max Moving Speed:	60m/min
Positioning Accuracy:	± 0.01-0.03	Powe Supply:	3×380V±10% 220V±10%
Package:	Wooden Case	Warranty:	1 Year

Precious metal precision laser cutting machine adopts Herolaser original double precious metal recycle system. Imported fiber laser source, high-profile cutting head, high precision rotary servo motors, with professional laser cutting control software and automatic following focalizing system, it can fully automatic adjust the focus position following the heights of bent cutting work piece to ensure the cutting quality.
Automatic feeding system and bangle,rings rotary cutting system can be optional.

Model Features

Original recycle system- full sealed double protection, cavity inner cut, recycle rate is up to 99.95%
High cutting precision, speed fast, narrow cutting seam, little heat-affected area, cutting surface smooth, no burrs.
10 years service life of fiber laser source.

Configuration

^#	^Item	^{Specification}	^Brand	^Remark
¹	^{Laser Source}	^800W	^Maxphotonics
²	^{linear motor}
³	^{Optical grating}	^{resolution 0.5μm}	^Spain
⁴	^Driver		^servotronix
⁵	^{Z axis Screw module group}
⁶	^{Laser cutting head}	^BT230
⁷	^{Precision linear guide rail}		^Hiwin
⁸	^Marble	^{18001350200}	^Shandong
⁹	^{Organ cover}	^Standard
¹⁰	^{Machining material}	^Standard		^{aviation aluminum-alloy}

Parameter

^{Working size}		^500×500(mm)
^{Max. Acceleration}		^1.2g
^{X AXIS}	^{Max. Moving speed}	^60m/min
	^Route	^500mm
	^{Positioning accuracy}	^±0.01mm
	^{Repeatition accuracy}	^±0.004mm
^{Y AXIS}	^{Max. Moving speed}	^60m/min
	^Route	^500mm
	^{Positioning accuracy}	^±0.01mm
	^{Repeatition accuracy}	^±0.004mm
^{Z AXIS}	^Route	^100mm

Working condition

¹	^{Working temperature}	^{-10℃～45℃}
²	^{Relativede Humidity}	^{＜90% no condenser}
³	^Environment	^{Good ventilation, no vibration}
⁴	^{Power supply}	^{3×380V±10% 220V±10%}
⁵	^{Power frequency}	^50Hz

Control system

The use of professional PC industrial computer operation, graphical interface, easy to operate, professional cutting control software can freely design a variety of graphics and text, real-time processing, support CAD, CorelDraw and other professional mapping software.
. High-quality industrial computer control operation
. High efficient, easy to operate CNC cutting system
. Z axis automatic tracking function
